867Mbps＋300Mbpsの高速接続が可能なIEEE802.11ac/n/a/g/b対応デュアルバンド無線LANルーター
・JAN/UPC：0886227832835
・TEKWIND型番：ASU-RT-AC56S
【主な特長】
・小型でスリムでスタイリッシュな高性能無線LANルーター
・転送速度最大867MbpsのIEEE802.11acに対応
・5GHzと2.4GHzのデュアルバンド対応
・接続機器を狙い撃つAi Radar機能で離れていても安定接続
・グラフィカルなASUSWRT画面ですべての設定を簡単変更
・ASUS AiCloudで外出先からでもデータにアクセス
・使い方が広がる便利なUSBポートを2ポート搭載
・100GBのオンラインストレージが使える1年間無料利用権を付属
製品についてお気軽にお問い合わせください
この製品を問い合わせる- 867Mbps＋300Mbps
- IEEE802.11ac/n/a/g/b
- Ai Radar
- Ai Cloud
製品画像
スペック
| インターフェース | 1 x USB3.0, 1 x USB2.0 |
|---|---|
| シリーズ | RTシリーズ |
- Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11d, IEEE 802.3, IEEE 802.3u, IEEE 802.11i, IEEE 802.11e, IPv4, IPv6
- Product Segment
AC1200 enhanced AC performance; 300+867Mbps
- Data Rate
802.11a : 6,9,12,18,24,36,48,54Mbps
802.11b : 1, 2, 5.5, 11Mbps
802.11g : 6,9,12,18,24,36,48,54Mbps
802.11n : up to 300Mbps
802.11ac: up to 867Mbps - Antenna
Internal PCB antenna x 4
- Operating
Frequency2.4GHz/5GHz
- Encryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , Radius with 802.1x, WPS support
- Firewall & Access
ControlFirewall: SPI intrusion detection,DoS protection
Access control: Parental control, Network service filter, URL filter, Port filter - Management
UPnP, DLNA, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Triger, Virtual Server, DMZ, Universal Repeater, System Event Log
- VPN Support
IPSec Pass-Throuth
PPTP Pass-Through
L2TP Pass-Through
PPTP server - WAN Connection
TypeInternet connection type :
WAN Bridge support
Multicast Proxy support
Multicast Rate Setting support - Utilities
．Download master
- support BT, NZB, HTTP, ED2K
- support encryption, DHT, PEX and magnet link
- upload and download bandwidth control
- download scheduling
．Media server:
Image: JPEG
Audio: mp3, wma, wav, pcm, mp4, lpcm, ogg
Video: asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
．QoS:
WMM
User definable rules for IP/MAC/Port. Upload and Download bandwidth management.
ACK/SYN/FIN/RST/ICMP with Highest priority
．Guest Network
2.4GHz guest network x 3, 5GHz guest network x 3
．Printer Server: multifunctional printer support(Windows nly), LPR protocol support
．File server: Samba and FTP server with account management
．PPTP VPN server
．Network map
．Traffic monitor - Ports
1 x RJ45 for 10/100/1000/Gigabits BaseT for WAN, 4 x RJ45 for 10/100/1000/Gigabits BaseT for LAN
USB 2.0 x 1
USB 3.0 x 1 - Button
WPS Button, Reset Button, Power Switch, Wireless on/off Button
- LED Indicator
PWR x 1
LAN x 1
WAN x 1
USB x 2
Wi-Fi x 2 - Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 2 A current - OS Support
Windows® 8.1
Windows® 8
Windows® 7
Windows® Vista
Windows® 2000
Windows® ME
Windows® XP
Windows® Server 2003
Windows® Server 2008
Mac OS X
Mac OS X 10.1
Mac OS X 10.4
Mac OS X 10.5
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
Linux Kernel (Support Ubuntu only)
Linux - Dimensions
147 x 205 x 66 cm (WxHxD)
- Weight
406 g
- Package Contents
1 x RT-AC56U Dual Band Wireless-AC1200 Gigabit Router
1 x RJ-45 cable
1 x Power adapter
1 x Warranty card
1 x QSG - Router Special
Features3G/4G data sharing, AiCloud, Printer server, AiDisK, Multiple SSIDs, Parental Control
- Operation mode
Wireless router mode
Access point mode
Media bridge mode
