ROG-STRIX-RX6700XT-O12G-GAMING
強力な冷却性と電力性能を備えたROG Strix Radeon™ RX 6700 XT OC Edition 12GB GDDR6
- カテゴリー
ROG-STRIX-RX6700XT-O12G-GAMINGの主な特長
- Axial-techファンデザインは、より多くのファンブレードとセンターファンの回転方向を逆にしてチューニングされています。
- 2.9スロット設計により、前世代と比較して冷却表面積が拡大し、これまで以上に熱的なヘッドルームが確保できます。
- Super Alloy Power IIは、プレミアム品質の合金製チョークコイル、固体ポリマーコンデンサ、高電流パワーステージを採用。
- MaxContactテクノロジーによりGPUチップとの接触が2倍になり、熱伝導が向上。
- 補強フレームはPCBの過度のねじれと横方向に曲がるのを予防。
- ASUS FanConnect II は、最適なシステム冷却のために2つのハイブリッド制御ファン2ヘッダーを装備。
- 通気性の高いバックプレートが、冷却アレイ内で熱風が再循環するのを防ぎます。
製品仕様 SPEC
基本仕様
- グラフィックスエンジン
- AMD Radeon™ RX 6700 XT
- Stream Processors
- 2560
- OpenGL
- OpenGL® 4.6
- Memory Speed
- 16 Gbps
- メモリーインターフェース
- 192-bit
- HDCP準拠
- HDCP 2.3
- 解像度
- 7680 x 4320
- NVlink/ Crossfire Support
- Yes for DirectX® 12 and Vulkan®
- 主な付属品
- 1 x ROG Velcro Hook & Loop
1 x Collection card
1 x Speedsetup Manual - 付属ソフトウェア
- ASUS GPU Tweak II & Drivers: please download all software from the support site.
- サイズ
- 322 x 141 x 56.5 mm
12.68 x 5.55 x 2.22 inches - 推奨PSU
- 650W
- 電源コネクター
- 2 x 8-pin
- その他
- * Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
** Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
*** All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products.
パッケージサイズ
- 幅(W)
- 23.3cm
- 奥行(D)
- 8.9cm
- 高さ(H)
- 40.5cm
- 重量
- 2.3kg
法令関連
- 電気用品安全(PSE)
- 対象外
- 電波法(TELEC認証)
- 対象外
- RoHS対応
- RoHS対応
