インテル® Core™ i7 プロセッサー搭載モデル
・JAN/UPC:0735858297066
・メーカー型番:BOXNUC5I7RYH
・TEKWIND型番:INT-BOXNUC5I7RYH
NUC5i7RYHは第5世代インテル® Core™ i7-5557U プロセッサーを搭載し、最高のパフォーマンスを提供するインテル® NUC です。
内蔵されているインテル® Iris™ グラフィックス 6100 により、臨場感あふれるゲームにも対応、豊かなマルチメディア体験をもたらします。また、インテル® ターボ・ブースト・テクノロジー 2.01 により、ユーザーのニーズに最適なパフォーマンスを提供します。
2.5 インチ HDD や M.2 SSD をサポートし、より多くのストレージを確保することが可能です。
製品についてお気軽にお問い合わせください
この製品を問い合わせるスペック
Processor | Intel® 5th Generation Core i7-5557U (3.1 GHz up to 3.4 GHz Turbo, Dual Core , 4 MB Cache, 28W TDP) |
---|---|
Memory | Dual-channel DDR3L SODIMMs 1.35V, 1333/1600 MHz, 16GB maximum |
Graphics | Intel® Iris™ Graphics 6100 1x mini HDMI 1.4a 1x mini DisplayPort 1.2 |
Audio | Up to 7.1 surround audio via Mini HDMI and Mini DisplayPort Headphone/Microphone jack on the front panel |
Peripheral Connectivity |
2x USB 3.0 ports on the back panel 2x USB 3.0 ports on the front panel (1x charging capable) 2x Internal USB 2.0 via header Consumer Infrared sensor on the front panel |
Storage | Internal support for M.2 SSD card (22x42, 22x60, or 22x80) Internal SATA3 support for 2.5¨ HDD/SSD (up to 9.5mm thickness) |
Networking | Intel® 10/100/1000Mbps Network Connection Intel® Wireless-AC 7265 M.2 soldered-down, wireless antennas (IEEE 802.11ac, Bluetooth® 4, Intel® Wireless Display) |
Enclosure | Silver with Black Top and Diamond Cut around the Top Aluminum and Plastic Dimensions : 115mm x 111mm x 48.7mm |
Power Adapter | 19V, 65W wall-mount AC-DC power adapter Multi-country plugs (IEC types A/C/G/I) |
Additional Features | Support for user-replaceable 3rd party lids NFC and AUX_PWR headers OS: Windows 7 & 8.1 logo’d; Linux compatibility VESA mount bracket and mounting hole support Low-acoustics active cooling design Kensington lock support Integration Guide 12-19V DC Power Input Power sensing circuit for protection against over-power shutdowns 3-year Advanced Warranty Replacement |
